BAT46W
SURFACE MOUNT SCHOTTKY BARRIER DIODE
Features
?
High Breakdown Voltage
?
Low Turn-on Voltage
?
Guard Ring Construction for Transient Protection
?
Lead, Halogen and Antimony Free, RoHS Compliant
"Green" Device (Notes 4 and 5)
Mechanical Data
?
Case: SOD-123
?
Case Material: Molded Plastic.
UL Flammability Classification
Rating 94V-0
?
Moisture Sensitivity: Level 1 per J-STD-020D
?
Terminals: Solderable per MIL-STD-202, Method 208
?
Lead Free Plating (Matte Tin Finish annealed over Alloy 42
leadframe)
?
Polarity: Cathode Band
?
Marking Information: See Page 3
?
Ordering Information: See Page 3
?
Weight: 0.01 grams (approximate)
Top View
Maximum Ratings
@TA
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
VRRM
VRWM
VR
100
V
Forward Continuous Current (See figure 4)
IF
150
mA
Repetitive Peak Forward Current (Note 1) @ tp
< 1.0s, Duty Cycle < 50%
IFRM
350
mA
Forward Surge Forward Current (Note 1) @ tp
= 10ms
IFSM
750
mA
Thermal Characteristics
Characteristic
Symbol
Value
Unit
Power Dissipation
PD
200
mW
Thermal Resistance, Junction to Ambient Air (Note 1)
Thermal Resistance, Junction to Ambient Air (Note 2)
RθJA
420
370
°C/W
Operating Temperature Range
TJ
-55 to +125
°C
Storage Temperature Range
TSTG
-55 to +150
°C
Electrical Characteristics
@TA
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
Reverse Breakdown Voltage (Note 3)
V(BR)R
100
—
—
V
IR
= 100
μA
Forward Voltage
VF
—
—
0.25
0.45
1.00
V
IF
= 0.1mA
IF
= 10mA
IF
= 250mA
Peak Reverse Current (Note 3)
IR
—
—
0.3
5.0
0.5
7.5
1.0
15
2.0
20
μA
VR
= 1.5V
VR
= 1.5V, T
J
= 60
°C
VR
= 10V
VR
= 10V, T
J
= 60
°C
VR
= 50V
VR
= 50V, T
j = 60°C
VR
= 75V
VR
= 75V, T
J
= 60
°C
Total Capacitance
CT
—
20
12
—
pF
VR
= 0V, f = 1.0MHz
VR
= 1.0V, f = 1.0MHz
Notes: 1. Part mounted on FR-4 board with recommended pad layout, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.
2. Part mounted on Polymide board with recommended pad layout, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.
3. Short duration pulse test used to minimize self-heating effect.
4. No purposefully added lead. Halogen and Antimony Free.
5. Product manufactured with Data Code V9 (week 33, 2008) and
newer are built with Green Molding Compound. Product manufactur
ed prior to Date
Code V9 are built with Non-Green Molding Compound and may contain Halogens or Sb
2O3
Fire Retardants.
BAT46W
Document number: DS30044 Rev. 16 - 2
1 of 3
www.diodes.com
July 2008
? Diodes Incorporated
